ICOM License-free Transceiver IC-F29DR3 / PMR446

The IC-F29DR3 is a robust, waterproof, and license-free handheld transceiver for professional use. It combines digital and analogue communication in one device for flexible and reliable communication across various applications.

Dual operating mode for maximum flexibility
The IC-F29DR3 can be used in both digital (32ch) and analogue (16ch) mode at the same time.

IP67 waterproof and dust-tight
Dust-tight and waterproof to a depth of one metre for 30 minutes - the IC-F29DR3 can withstand even the harshest environmental conditions and is ideal for outdoor use.

Clear sound in any environment
The powerful 1500 mW speaker provides louder and clearer audio, even in noisy environments.

Optimised group call communication
Digital Common ID can be used for a group call. Similar to analogue CTCSS and DTCS codes, channels can be individually programmed to enable direct connections.

VOX for hands-free operation
The radio can be operated hands-free with an optional headset.

User-friendly voice announcement
The device provides information about the current channel number as well as zone and mode selection by voice announcement to ensure simple operation.

Customised ring Tones for quick recognition
Call your group members with 12 types of ring tone. A pre-programmable emergency ring tone provides additional safety in critical situations.

Further features at a glance

• 26 hours operating time
• Lone Worker Function
• AquaQuake
• Channel Set Mode
• Power ON scan
• Tone scan (analogue)
• Nuisance delete
• Answer back call (analogue)
• LED light indicator
• Status Call (RX only)
• PC programmable
• AMBE+2™ dPMR™ standard vocoder

Technical Data

Usable Channels	16 channels (analogue) 32 channels (digital)
Output power	500 mW
Audio Output Power	Internal speaker 1500 mW External speaker 400 mW
Range	<11 km (in open environments)
Battery capacity	2400 mAh (type)
Operating time	<26 h
Operating temperature	-25 to + 55 °C
Waterproof rating	IP67
Dimensions (WxHxD)	52 x 112 x 30 mm
Weight	270 g

---

• IC-F29DR3 transceiver
• BC-213 rapid charger
• BC-242 mains adapter
• BP-280 battery pack
• MB-133 belt clip
