KUS Analogue Clock / 52 mm
SVB item number: 21546
Manufacturer no.: 21546
Analogue clock with white dial. Product details
Having issues?
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
Are you already using this item?
Add to my boat now.
Available variants
Product data
- SVB item number 21546
- EAN 7025926093045
- Manufacturer no. 21546
- Description KUS - Analogue Clock
- Instrument type Clock
- Display options Time
- Operating voltage 12 V
- Display-Ø 52 mm
- Backlight Red, Yellow
- Colour display No
- Dial colour White
- Housing colour White
- Round instrument Yes
- NMEA2000 No
- NMEA0183 No
- With transducer No
- Material Plastic
Product details
Analogue clock with white dial.
General characteristics of the KUS SEA V-Series
Connections
Pin 1 - BLUE = Battery NEG (terminal 31)
Pin 2 - RED = 12 or 24 V Battery POS (terminal 30, permanent POS)
Pin 3 - BLACK = to push button (time setting)
Pin 4 - ORANGE = dash light (only red possible) (terminal 58)
Pin 5 - YELLOW = to push button (time setting)
Note
General characteristics of the KUS SEA V-Series
- Widely used in marine,vehicle, generators/gen set and bus etc fields
- Passed all kinds of strict tests, including environmental and vibration test and has relevant CE certificate
- Clear, elegant, beautiful dial and high-performance material
- Reverse polarity protection and anti-fogging performance
- Installation: lock it into baseboard directly
- Connector: Easy installation with multi-plug socket connection design
- Options of red or yellow color background light
- Working voltage:12V/24V
- Working temperature: - 40 to 85°C
- Display precision: <3°
- IP7 Protection rating for entire gauge; can work up to 1m under water
Connections
Pin 1 - BLUE = Battery NEG (terminal 31)
Pin 2 - RED = 12 or 24 V Battery POS (terminal 30, permanent POS)
Pin 3 - BLACK = to push button (time setting)
Pin 4 - ORANGE = dash light (only red possible) (terminal 58)
Pin 5 - YELLOW = to push button (time setting)
Note
- The clock can be operated with a 12 and 24 volt electrical system without series resistor.
- Since the clock has no back-up battery, it should be clamped to the permanent positive (terminal 30). In case of missing operating voltage, the clock stands still and can be quickly set to the correct time with the push button (included) once reconnected.
- The clock only comes with a red dash light.
Features
Discover the features that make this product stand out. From technical details to special functions – we’ve summarized all the key information for you.
Material
Plastic
Documents
Drawing
PDF (252,69 KB)
Manual
PDF (686,68 KB)
Manual
PDF (576,80 KB)
Manual
PDF (310,20 KB)
Short manual
PDF (533,39 KB)
Product safety
