LED Surface-Mounted Interior Light

customers like: Luminosity

To product

At a glance!

Replaceable light source

Surface mounted

Brass

customers like: Design

by Joachim A.

kein Kommentar

forgiven What a pleasure to find ceiling lights identical to those originally placed after 20 years.

by Maurice D.

Magnificent It's wonderful to find, even today, spots identical to those fitted by the yard, for a 20-year-old boat.

by Maurice D.

Always very well. Delay a little long but depends on the supplier of the lamps, otherwise all O.K.

by Maurice D.

Replacement order because light color in red and white possible! My lights in the Bavaria could not be equipped with the new LED light sources in red and white. Since the design of the lamp corresponds exactly to that of the old lamps, I am now gradually replacing all of the lamps.

by Thomas F.

Product data

SVB item number 88480
Description LED surface-mounted Iiterior light
Light type Ceiling light
Operating voltage 12 V, 24 V
Voltage range 10 - 30 V
Illuminant LED
Light colour Warm white
Brightness 60 lm
Watts 1.8 W
Dimmable No
USB charging port No
With switch Yes
With Illuminant Yes
Replaceable light source Yes
Installation type Surface mounted
Surface finish silver
Material Brass
Outer-Ø 100 mm
Ø 100 mm
Base G4
Light temperature 2800 - 3300 K

SVB recommends

Replacement Switch for Interior Surface-Mounted Light

only €7.00

Replacement O-Ring for Indoor Surface-Mounted Light / black

only €5.45

Accessories

Spare LED Bulb 9D

only €5.95

LED G4 Light Bulb / warm-white/red

only €9.50

G4 LED Illuminant / cold-white/blue

only €9.50

WAGO Splicing Connector / 0.2-4.0 mm²

only €0.90

Product details

Chrome-plated LED surface-mounted light with on/off switch and swivelling reflector. Chrome-plated brass housing. Beam angle: 120°. Operating temperature: -20 °C to +45 °C. Colour temperature: 2900-3200 K. Power consumption: 0.15 A. Light duration: 50,000 hours.

We recommend the following as replacement bulbs:

Item 12394 - LED G4 / 10-30 V / 140 lm / 1.3 W / warm white
Item 21459 - LED G4 / 10-30 V / 160 lm / 1.7 W / warm white/red
Item 21460 - LED G4 / 10-30 V / 160 lm / 1.7 W / warm white/blue

Note on changing the LEDs
Replacing an illuminant requires removing the light glass. The glass is held in place with a black plastic ring in the housing of the light.
This ring must first be removed. There is a small slot opening on the ring (difficult to see) and 3 holding tabs on the outside of the ring. See item # 88482. Place the blade of a small screwdriver just next to the slot on the outside of the plastic ring, either to left or right of the slot, and gently push the ring toward the center of the glass. This releases a retaining tab and the ring and glass can then be easily removed.

Operating voltage

12 V 24 V

Illuminant

LED

Light colour

Warm white

With switch

With Illuminant

Replaceable light source

Installation type

Surface mounted

Material

Brass

Product safety

What other SVB customers have to say

100% real reviews

15 customer reviews

4.3 (out of 15 ratings)

5 Stars

(9)

4 Stars

(3)

3 Stars

(1)

2 Stars

(2)

1 Stars

(0)

Advantages
Light colour (3)
Price/performance ratio (2)
Quality (3)
Mounting/Installation (5)
Design (6)
Luminosity (5)
Brightness (4)
Material (3)
Light intensity (4)

Disadvantages
Light colour (2)
Price/performance ratio (4)
Quality (3)
Mounting/Installation (1)
Material (1)

Customer images (1) from all reviews

by Didier C.

11/20/2025 Verified purchase Variant: 88480

Overall satisfied

Satisfied with the delivery

Advantages
Brightness
Material
Quality
Mounting/Installation
Design
Luminosity
Light intensity

Disadvantages
Light colour
Price/performance ratio

by Winfried K.

7/6/2025 Verified purchase Variant: 88480

Ceiling lamp bow cabin

Nice surface-mounted lamp, but warm white is not my thing, I prefer cold white, but I'm still satisfied

Advantages
Brightness
Material
Price/performance ratio
Quality
Mounting/Installation
Design
Luminosity
Light intensity

Disadvantages
Light colour

Images for this rating

by Bertram K.

10/5/2023 Verified purchase Variant: 88480

Super fast. Corresponds to the original

by Norbert B.

9/6/2023 Verified purchase Variant: 88480

Everything OK.

Product was exactly as described in the catalog.

by Thomas F.

3/22/2023 Verified purchase Variant: 88480

LED Surface-Mounted Interior Light

Replacement order because light color in red and white possible!

My lights in the Bavaria could not be equipped with the new LED light sources in red and white. Since the design of the lamp corresponds exactly to that of the old lamps, I am now gradually replacing all of the lamps.

Advantages
Light colour
Price/performance ratio
Quality
Mounting/Installation
Design
Luminosity

View all ratings

Rate product

How would you rate this product?

Disappointed

Completely fails to meet my expectations

Poor

Only some expectations are met

Meets my basic expectations

Good

Slightly better than my general expectations

Excellent

Fully exceeds my expectations

Click on the stars to rate

Customers ask customers

Technical question

Ali Cenk K. | Jan 30, 2022

Hi, what is the difference between this and below model? https://www.svb24.com/en/bavaria-led-interior-dome-light.html#19884

Answer

W P. | Feb 3, 2022

There is no difference. We already had #19884# in our range before we started the spare parts logistics for BAVARIA and received the same lamp (#88480#) from BAVARIA as a spare part.
