EPROPULSION SPIRIT 1.0 PLUS L Electric Outboard Motor / long shaft + bag set
SVB item number: 33794
Quiet, environmentally friendly and powerful! The SPIRIT 1.0 PLUS electric outboard from ePropulsion is portable and easy to store, and delivers the equivalent to approx. 3 HP, making it perfect for dinghies, RIBs and sailboats up to 1.5 tons. It has a long shaft and boasts high performance with minimal noise. Product details
only
€2,375.00
Shipping information:
Shipping of bulky goods
Expected to be in stock within 3-4 weeks
Having issues?
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
Are you already using this item?
Add to my boat now.
Available variants
Product data
- SVB item number 33794
- Description ePropulsion - SPIRIT 1.0 PLUS L + bag set
- Type of drive Electric
- Power 3 HP
- Shaft height Long shaft
- Steering type Tiller
- Operating voltage 48 V
- Watts 1000 W
- For boats up to 1500 kg
- Max. thrust 32 kg
- Trim Manual
- Speed levels Continuously variable
- GPS No
- Adjustable shaft No
- with on-board computer Yes
- Area of application Salt water, Fresh water, Brackish water / Mixed operation
- Weight 19.6 kg
- Recuperation No
- Shaft height 75 cm
- Series Spirit
- Shipping information Shipping of bulky goods
Product details
Quiet, environmentally friendly and powerful! The SPIRIT 1.0 PLUS electric outboard from ePropulsion is portable and easy to store, and delivers the equivalent to approx. 3 HP, making it perfect for dinghies, RIBs and sailboats up to 1.5 tons. It has a long shaft and boasts high performance with minimal noise. Extremely low-maintenance.
Quiet and environmentally friendly
A significant advantage electric outboards have over petrol motors is how much quieter they are. The maximum operating noise of the Spirit 1.0 is the equivalent dB level to a normal conversation. This makes it perfect for anglers, as the motor does not disturb fish.
Light and space-saving
The electric motor is easy to dismantle and can be easily stowed away. With a low total weight of only 19.6 kg, it's extremely portable. The specially designed carry bag makes transportation even easier. Thanks to plug-and-play, it couldn't be simpler to install and vice-versa.
Powerful 1276 Wh battery
The integrated battery has an output of 1276 Wh and provides 50% more runtime at top speeds than comparable motors. Reach up to 35 km at lower speeds. The battery is also waterproof and floatable, so there's no need to worry if it falls into the water. Thanks to 48 V nominal voltage, the Spirit series can also be operated with external batteries. Matching chargers and solar modules are available separately. The display on the motor shows the charge level, remaining range and operating voltage in real time.
The right shaft
Choose the shaft length that is right for your boat to ensure maximum efficiency and performance of your Epropulsion electric outboard. Refer to the following table to quickly and easily determine the appropriate motor. You only need to know the transom height of your boat.
| Transom height | Recommended model |
| 300 mm to 350 mm | Spirit 1.0 PLUS XS |
| 350 mm to 450 mm | Spirit 1.0 PLUS S / EVO S |
| Higher than 450 mm | Spirit 1.0 PLUS L / EVO L |
Speed and range*
| Output (W) | Speed (km/h) | Runtime (hh:mm) | Range (km) |
|---|---|---|---|
| 35 | 3.5 | 36:25 | 129 |
| 65 | 4.3 | 19:35 | 85.3 |
| 125 | 5.6 | 10:00 | 56 |
| 250 | 7.1 | 5:00 | 35.5 |
| 500 | 8.5 | 2:30 | 21.3 |
| 750 | 9.2 | 1:40 | 15.3 |
| 1000 | 10,0 | 1:15 | 12.5 |
Technical data
| Power | 1000 W / 3 HP |
| Shaft length | 750 mm (long shaft) |
| Control | Tiller |
| For boats up to | 1500 kg |
| Battery capacity | 1276 Wh |
| Battery life | 800 cycles at 80% discharge |
| Battery charging time | approx. 8 hours |
| Nominal current | 20.8 A |
| Nominal voltage | 45.6 V |
| Recuperation | No |
| Trim angle | 0°, 7°, 14°, 21° |
| Tilt angle | 75° |
| Propeller | 11" x 5.8" (2-blade) |
| Dimensions (h x w x d) | 880 x 273 x 1235 mm |
| Weight | 10.8 kg (motor) 8.8 kg (battery) |
| Included in delivery | 1x motor, 1x battery, 1x battery charger, 2x pin, 2x magnetic klll switch |
Features
Discover the features that make this product stand out. From technical details to special functions – we’ve summarized all the key information for you.
Power
3 HP
Long shaft
Steering type
Tiller
Operating voltage
48 V
Max. thrust
32 kg
Contains lithium
with on-board computer
Delivery contents
- SPIRIT 1.0 Electric Outboard
- Battery 1276 Wh
- Charger 10 A
- 2x locking pin
- 2x magnet clip for emergency stop
- Operating instructions, warranty card, certificates
- Bag set
Spare parts
Spare part finder
How it works
Product safety
Battery capacity
1276 Wh
Customers ask customers
No questions asked yet. Be the first to ask a question!
Comparison
Availability / Price
Item no.
33794
31065
Customer ratings
Description
ePropulsion - SPIRIT 1.0 PLUS L + bag set
ePropulsion - SPIRIT 1.0 PLUS L
Watts
1000 W
1000 W
Shaft height
Long shaft
Long shaft
For boats up to
1500 kg
1500 kg
Weight
19.6 kg
19.6 kg
GPS
Power
3 HP
3 HP
Steering type
Tiller
Tiller
Type of drive
Electric
Electric
Series
Spirit
Spirit
Operating voltage
48 V
48 V
Area of application
Salt water, Fresh water, Brackish water / Mixed operation
Salt water, Fresh water, Brackish water / Mixed operation
Trim
Manual
Manual
with on-board computer
Max. thrust
32 kg
32 kg
Adjustable shaft
Speed levels
Continuously variable
Continuously variable
Recuperation
Shaft height
75 cm
75 cm
Battery capacity
1276 Wh
1276 Wh
UN number
UN 3481
Transport class
9
