RAYMARINE CYCLONE Open Array Radar / 121cm
SVB item number: 81844
Manufacturer no.: T70492
Cyclone radars from Raymarine provide mariners with unmatched situational awareness, gving them the confidence to navigate busy waterways with ease. Each model features innovative technology and is sure to impress with high speed 60 RPM imaging. Antenna length: 121 cm. Power: 55 W. Supplied with 15 m radar cable. Product details
Recommended retail price:
€8,919.05
only
€8,419.95
-6%
You save: €499.10
Shipping information:
Shipping of bulky goods
Item will be ordered for you
Having issues?
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
Are you already using this item?
Add to my boat now.
Available variants
At a glance!
Product data
- SVB item number 81844
- EAN 723193836620
- Manufacturer no. T70492
- Description RAYMARINE - CYCLONE open array radar / 121cm
- Antenna technology Slot antenna
- Tx power 55 W
- Max. range 72 nm
- Beam width 1.99 °
- Doppler mode Yes
- Rotational speed 60 RPM
- WiFi No
- (M)ARPA Yes
- Compatible displays AXIOM+ RV, AXIOM Pro S, AXIOM Pro RVX, AXIOM 2 Pro S, AXIOM 2 Pro RVM
- Weight 25 kg
- Operating voltage 12 V, 24 V
- Shipping information Shipping of bulky goods
Product details
Cyclone radars from Raymarine provide mariners with unmatched situational awareness, gving them the confidence to navigate busy waterways with ease. Each model features innovative technology, such as beam sharpening, detection capabilites and bird mode, and is sure to impress with high speed 60 RPM imaging.
Delivery includes 15 m radar cable.
Made for Extremes
The radar has been designed for use in winds of up to 100 knots and can therefore withstand the most extreme weather conditions. Meets the commercial grade IEC 62388 standard for ship bourne radar.
360° Degrees of Awareness
Fast 60 RPM rotational speed delivers accurate target tracking for reliable 360° situational awareness.
Doppler and ARPA Target Tracking
Integrated Doppler target tracking makes it easy to interpret dangerous and safe targets. ARPA technology additionally enables professional target tracking of up to 50 targets with the same advanced ARPA technology.
.
RangeFusion Technology
RangeFusion technology combines short and long pulses to quickly and clearly identify and display both close range and distant targets in a single high-resolution radar image that is quick and easy to interpret.
Designed with Fishing Intelligence
The Cyclone is performance tuned for locating sea birds. This means gain and tune settings are intelligently optimised for imaging distant sea birds.
Low Profile and Adaptable Installation Options
Standing at just 335 mm, the radar features an impressively low profile. Furthermore, the antenna base has a built-in cable gland that neatly conceals all cable connections.
Technical data
Delivery includes 15 m radar cable.
Made for Extremes
The radar has been designed for use in winds of up to 100 knots and can therefore withstand the most extreme weather conditions. Meets the commercial grade IEC 62388 standard for ship bourne radar.
360° Degrees of Awareness
Fast 60 RPM rotational speed delivers accurate target tracking for reliable 360° situational awareness.
Doppler and ARPA Target Tracking
Integrated Doppler target tracking makes it easy to interpret dangerous and safe targets. ARPA technology additionally enables professional target tracking of up to 50 targets with the same advanced ARPA technology.
.
RangeFusion Technology
RangeFusion technology combines short and long pulses to quickly and clearly identify and display both close range and distant targets in a single high-resolution radar image that is quick and easy to interpret.
Designed with Fishing Intelligence
The Cyclone is performance tuned for locating sea birds. This means gain and tune settings are intelligently optimised for imaging distant sea birds.
Low Profile and Adaptable Installation Options
Standing at just 335 mm, the radar features an impressively low profile. Furthermore, the antenna base has a built-in cable gland that neatly conceals all cable connections.
Technical data
| Power supply | 10.2 - 31.2 V DC |
| Power consumption | 70 W (typical) 170 W (max.) |
| Operating temperature range | -25 to +55 °C |
| Antenna size | 121 cm |
| Output power | 55 W |
| Max. range | 72 nm |
| Rotation speed | 12 / 24 / 36 / 48 / 60 RPM |
| Beam width (vertical) | 25° |
| Beam width (horizontal) | 1.99° |
| Boot up time | 40 seconds |
| Transmitter frequency | 9370 / 9400 / 9430 MHz (selectable) |
| Receiver characteristic | Linear |
| Receiver noise | Less than 5 dB |
| Data connection | 1x Raynet connector |
| Waterproof | IPX6 |
| Max. wind speed | 100 kts |
| Dimensions | Length: 1336 mm Pedestal: 388 x 360 x 335 |
| Weight: | 25 kg |
| Included | Open array radar, VCM100, 15 m power cable, 15 m data cable and mounting material |
Features
Discover the features that make this product stand out. From technical details to special functions – we’ve summarized all the key information for you.
(M)ARPA
Product safety
Customers ask customers
No questions asked yet. Be the first to ask a question!
Comparison
Availability / Price
Item no.
81844
81843
81845
Customer ratings
Description
RAYMARINE - CYCLONE open array radar / 121cm
RAYMARINE - CYCLONE open array radar / 91cm
RAYMARINE - CYCLONE open array radar / 182 cm
Weight
25 kg
23 kg
27 kg
WiFi
Tx power
55 W
55 W
55 W
Operating voltage
12 V, 24 V
12 V, 24 V
12 V, 24 V
Antenna technology
Slot antenna
Slot antenna
Slot antenna
Doppler mode
Max. range
72 nm
72 nm
72 nm
Rotational speed
60 RPM
60 RPM
60 RPM
(M)ARPA
Beam width
1.99 °
2.83 °
1.32 °
Compatible displays
AXIOM+ RV, AXIOM Pro S, AXIOM Pro RVX, AXIOM 2 Pro S, AXIOM 2 Pro RVM
AXIOM+ RV, AXIOM Pro S, AXIOM Pro RVX, AXIOM 2 Pro S, AXIOM 2 Pro RVM
AXIOM+ RV, AXIOM Pro S, AXIOM Pro RVX, AXIOM 2 Pro S, AXIOM 2 Pro RVM
