ATTWOOD SAHARA Mk2 1200 Bilge Pump / 12 V
SVB item number: 76533
Manufacturer no.: 5512-7
The SAHARA Mk2 automatic bilge pump has a built-in float switch and is easy to install and service. It features a patented impeller that eliminates air-locks in the system, so that the pump will not run dry and burn out. It also has an integrated non-return check valve to prevent water from running back into the bilge. Suitable for fresh and salt water. Product details
Having issues?
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
Are you already using this item?
Add to my boat now.
Available variants
Product data
- SVB item number 76533
- EAN 022697023483
- Manufacturer no. 5512-7
- Description ATTWOOD - SAHARA MK2 1200 bilge pump
- Operating voltage 12 V
- Recommended fuse 6 A
- Max. flow rate 76 l/min
- Max. flow rate 1200 gph
- Operation Manual, Automatic
- Float switch Integrated
- Hose connection 25, 28 mm
- Hose connection 1", 1 1/8"
- Length 155 mm
- Width 88 mm
- Height 103 mm
Product details
The SAHARA Mk2 automatic bilge pump has a built-in float switch and is easy to install and service. It features a patented impeller that eliminates air-locks in the system, so that the pump will not run dry and burn out. It also has an integrated non-return check valve to prevent water from running back into the bilge. Suitable for fresh and salt water.
Integrated float switch
The built-in float switch activates the pump when water reaches a height of 50 m and deactivates at a height of 19 mm.
Flexible installation possibilities
The design also features a mounting hole pattern that allows for the most flexible installation options. This makes it easy to replace any top bilge pump in its category (e.g. Johnson Ultima, Johnson Float, Rulemate or Shoreline), without having to drill new holes.
Easy and quick to service
The pump has been innovatively designed for simple system maintenance. There's no need to dismantle the plumbing or mounting feet. If necessary, the basket can be removed by a click lock and the pump can be inspected and cleaned.
Integrated float switch
The built-in float switch activates the pump when water reaches a height of 50 m and deactivates at a height of 19 mm.
Flexible installation possibilities
The design also features a mounting hole pattern that allows for the most flexible installation options. This makes it easy to replace any top bilge pump in its category (e.g. Johnson Ultima, Johnson Float, Rulemate or Shoreline), without having to drill new holes.
Easy and quick to service
The pump has been innovatively designed for simple system maintenance. There's no need to dismantle the plumbing or mounting feet. If necessary, the basket can be removed by a click lock and the pump can be inspected and cleaned.
Note:
The actual delivery rate of a bilge pump may deviate from the manufacturer's specifications, as it depends largely on the installation and power supply conditions. If the battery is fully charged, it will provide the necessary voltage to operate the pump at full power, but if the battery is only partially charged, the flow rate can be significantly reduced. The cable cross-section also plays an important role - if the supply lines are too long or too thin, voltage losses will occur, which will impair the performance of the pump. The hose diameter used also has an impact on efficiency: The larger the diameter, the lower the flow resistance and the better the actual delivery rate of the pump.
Features
Discover the features that make this product stand out. From technical details to special functions – we’ve summarized all the key information for you.
Operating voltage
12 V
76 l/min
Float switch
Integrated
Hose connection
25 mm
28 mm
Hose connection
1"
1 1/8"
Product safety
Customers ask customers
No questions asked yet. Be the first to ask a question!
More "Customers ask customers" available in the following languages
Comparison
Availability / Price
Item no.
76533
76532
76530
76531
76534
Customer ratings
Description
ATTWOOD - SAHARA MK2 1200 bilge pump
ATTWOOD - SAHARA MK2 800 bilge pump
ATTWOOD - SAHARA MK2 500 bilge pump
ATTWOOD - SAHARA MK2 800 bilge pump
ATTWOOD - SAHARA MK2 1200 bilge pump
Width
88 mm
88 mm
88 mm
88 mm
88 mm
Height
103 mm
103 mm
103 mm
103 mm
103 mm
Recommended fuse
6 A
2 A
3 A
5 A
3 A
Length
155 mm
155 mm
155 mm
155 mm
155 mm
Operating voltage
12 V
24 V
12 V
12 V
24 V
Max. flow rate
76 l/min
50 l/min
32 l/min
50 l/min
76 l/min
Float switch
Integrated
Integrated
Integrated
Integrated
Integrated
Hose connection
25, 28 mm
19, 25 mm
19, 25 mm
19, 25 mm
25, 28 mm
Hose connection
1", 1 1/8"
3/4", 1"
3/4", 1"
3/4", 1"
1", 1 1/8"
Operation
Manual, Automatic
Manual, Automatic
Manual, Automatic
Manual, Automatic
Manual, Automatic
Max. flow rate
1200 gph
800 gph
500 gph
800 gph
1200 gph
