B&amp;G VULCAN 9FS / Touch

To product

B&G VULCAN 9 FS + TrueHeading AIS Transponder Bundle

€2,246.96

only €1,699.95

To product

B&G VULCAN 9 FS + ForwardScan Bundle

€1,986.11

only €1,399.95

customers like: Price / performance ratio

To product

At a glance!

Display size : 9 Inch

customers like: Mounting / Installation

by Sven F.

Great device! The installation was easy, installation templates and all necessary material are included. The device itself was already known to me in the smaller version (Vulcan 5). You will see how it works on the boat, but the Sailsteer display is just awesome.

B&G - VULCAN 9 FS GPS, 9 inches For me, the Simrad Go7 was just a bit too small on the 24-foot Tri, and the "Sailsteer", which is particularly useful for sailors, was also missing. So please 1x VULCAN 9 FS The first one was unfortunately defective and was returned The second is a great device, many functions Simple operation, just read through the most important things and try them out, then it works! The device is relatively light and does not have a deep, heavy housing, so it is ideal for rotary bracket mounting. Like the old Simrad, the B&G also has fast and good satellite reception, no additional antenna is necessary on the GRP boat. Like the Simrad, the Vulcan can do something on the back get hot, a gentle breeze to cool down can never hurt Next week on the water and try everything!

by Bram J.

Arrived. Vulcan 9 The product arrived, together with the plotter there was an assembly manual, and a quick installation guide. The complete guide with all the operations that this plotter can do is missing. How do I get the complete guide to take advantage of all the functions of this article?

by Nicola G.

by KLaus-Dieter M.

Super execution navigation

Screen Mirror The main reason for purchasing Vulcan was Screen Mirror. Plan is to keep Plotter at Vav Table, tablet at helm. Difficulties downloading B&G software, Link software... No help from B&G. Dissapointed!!!.

by Brendan M.

Get a compatible chart order now

Product data

SVB item number 81494
EAN 9420024153710
Manufacturer no. 000-13214-001
Description B&G - VULCAN 9FS
Series Vulcan
Display size 9 Inch
Resolution 800 x 480 px
Viewing angle 80 °
Screen brightness 1200 Nits
Operating mode Touch screen
NMEA2000 Yes
NMEA0183 No
WiFi Yes
Bluetooth No
Ethernet / Network No
Radar capable Yes
Tablet control Yes
Sonar module Yes
Sonar type CHIRP / Fishfinder, DownScan, SideScan, ForwardScan, Numerical depth
Viewing angle Downwards, Sidewards, Forwards
Compatible Navico transducers P79, P319, HDI, HST-WSBL, TotalScan, ForwardScan, Active Imaging, StructureScan HD
Nautical chart support Yes
Sea Charts C-MAP REVEAL, C-MAP DISCOVER, Navionics+, Navionics Platinum+, NV Charts
Installation width 231 mm
Installation height 155 mm
With transducer No
Sonar view Fish, Bottom structure
IP protection class IPX7

SVB recommends

NMEA2000 Starter Kit / Micro-C

only €133.95

-14%

B&G HALO20 Pulse Compression Radar

only €2,099.95

-10%

B&G ZC2 Remote Control

only €471.95

-9%

NAVICO P319 Through-Hull Transducer - 9/5-pin plug

only €209.95

-10%

NAVICO TotalScan™ Transom Transducer

only €387.95

NMEA2000 Starter Kit / Micro-C

only €133.95

-14%

B&G HALO20 Pulse Compression Radar

only €2,099.95

-10%

B&G ZC2 Remote Control

only €471.95

-9%

NAVICO P319 Through-Hull Transducer - 9/5-pin plug

only €209.95

-10%

NAVICO TotalScan™ Transom Transducer

only €387.95

Accessories

-10%

NAVICO Navico 4 Pin Power Cable for Simrad GO/NSS evo3 and B&G Vulcan/Zeus3 Series

only €42.95

-10%

NAVICO NMEA2000 608 Wind Sensor

only €459.95

-18%

NAVICO ForwardScan Transducer

only €749.95

-20%

NAVICO PRECISION-9 Compass

only €639.95

NAVICO Fuel Flow Transmitter

only €274.95

-20%

NAVICO NAIS-500 AIS-Transponder

only €789.95

-10%

B&G ZC2 Remote Control / horizontal

only €523.95

-10%

B&G ZG100 GPS-Antenna

only €297.95

Product details

The B&G VULCAN 9FS chartplotter navigation display is the perfect way to expand the capabilities of sportboats, cruisers, and smaller centre consoles with plug-and-play support for Simrad Broadband Radar™ and Halo™ Pulse Compression radar systems. Behind a super-bright, multi-touch widescreen display lies a built-in GPS receiver, GoFree® Wi-Fi, and industry standard NMEA 2000® connectivity. Connect with smartphones and tablets, control your onboard sound system, monitor engine data, and choose from an array of built-in sonar technology to cruise with confidence and find fish like a pro.

Key Features

Easy to use multi-touch interface
Fully-featured chartplotter with widest available cartography support (Insight, Navionics, CMAP)
Radar display for B&G Broadband 3G™/4G™ and Halo™ Pulse Compression radar systems
Includes worldwide basemap
Plan smarter with TripIntel™ technology
Support for Navionics Autorouting and Easy Routing
9-inch flush or bracket mount display
Widescreen with bright LED backlight
High-speed 10 Hz GPS receiver
Built-in Broadband Sounder™, CHIRP sonar, StructureScan® HD imaging or ForwardScan™ sonar support (transducer required)
Built-in GoFree™ Wi-Fi
Dual microSD card slots
NMEA 2000® compatible

Easy-to-Use Multi-Touch Display
The VULCAN 9FS offers true ease of use with intuitive touchscreen controls that smartphone and tablet users will find instantly familiar. Tap to create or select waypoints, pinch to zoom, or tap and drag to pan smoothly across charts. Simple home screen and menu layouts make all functions quickly accessible, with large and clearly-captioned icons that are easy to recognise and tap.

Chartplotter Navigation & Waypoint Management
The VULCAN 9FS is a fully-featured chartplotter, with support for the widest available range of cartography options including C-MAP® MAX-N, Navionics®, Insight®, Insight Genesis®, and NV Digital® Charts. Navigate confidently to destinations near and far, with the flexibility to choose charts that best fit your needs and location. Set and record those destinations easily with simple waypoint mangement: mark waypoints with a touch, and assign meaningful names that make it easy to look up your desired destination whether you’ve mapped out ten places or a thousand.

Expand your View with a B&G Radar Device
The B&G VULCAN 9FS is a fully-featured radar display with plug-and-play connectivity to B&G Broadband 3G™, Broadband 4G™, and Halo™ Pulse Compression radar systems. Cruise confidently through crowded harbours, navigate safely in poor visibility, keep an eye on distant weather cells, and find flocks of feeding birds that hint at good fishing spots. Automatic tuning helps to provide a clear radar picture in any conditions, while radar overlay combines radar data with navigational charts for an easy-to-interpret view of your surroundings.

Fully Customisable Interface
The B&G VULCAN 9FS is fully customisable to suit your vessel and your favourite on-water activities – from power boating, to fishing, to water sports. Customise your home screen with shortcuts to the features you use most, and personalise it with your choice of wallpaper. Adjustable split-screen views and customisable panel layouts let you see everything you need on-screen at once, whatever your activity.

Plan Smarter with TripIntel™ Technology
Designed for power boaters, TripIntel technology tracks and displays the key information you need to plan safe and enjoyable days on the water. Make smart decisions with fuel range overlaid on charts, easy access to current and future tide levels, and a detailed history of your previous trips including the route you took and how your boat performed.

Easier Navigation with Automatic Routing
Automatic routing brings the convenience of in-car navigation to boating, helping you to plot a route and get underway with less delay. Simply select a destination, and your B&G VULCAN 9FS display will suggest the shortest, safest route taking into consideration the draught and dimensions of your vessel. This feature is available with Navionics+ or Navionics Platinum charts (Navionics Autorouting), and with Jeppesen CMAP MAX-N+ charts (Jeppesen Easy Routing).

Built-in 10 Hz GPS receiver*
With a high-speed GPS receiver updating your position ten times every second, the B&G VULCAN 9FS is ideal for use aboard fast-moving RIBs and powerboats. Watch your boat’s movement tracked smoothly, accurately, and in real-time, without ‘jumping’ from point to point on the display. * Built-in GPS receiver works in any bracket-mount installation, and when flush-mounted with most fibreglass hulls. When flush-mounted in a metal hulled vessel, an external GPS receiver, such as the B&G ZG100, may be required.

Cruise Charting View
Designed with power boating in mind, the B&G VULCAN 9FS offers a unique Cruise Charting page that brings together crucial navigation data and charts in one easily readable display. Choose the information most relevant to your crusing style and on-water activities with the ability to edit on-screen data items.

NMEA 2000® Engine Monitoring & Instrumentation
The B&G VULCAN 9FS connects to any NMEA 2000®-capable equipment aboard your vessel including outboard and inboard engines; fuel level and flow meters; speed, heading, and water temperature sensors; and much more. Create your own custom digital instrument displays, bringing a wealth of information to even the most crowded dash while keeping a clean look with as few gauges as possible.

Watch your Depth with Built-in Sonar
Knowing the true depth beneath your hull can help you enjoy your time on the water with fewer worries, and makes it easier to locate suitable anchorages in unfamiliar waters. With built-in sonar, just add a suitable sonar transducer for accurate, real-time depth tracking. A scrollable depth history view lets you track back and easily set waypoints for promising anchorages, while StructureScan Imaging™ combines DownScan and SideScan sonar to offer a picture-like view of the bottom beneath your vessel.

Cruise Confidently with ForwardScan™ Sonar
Using an optional ForwardScan transducer, this forward-looking sonar technology provides a clear two-dimensional image of the bottom in front of your vessel, allowing you to navigate shallow or poorly-charted waters with confidence. With real-time updates and a forward-looking view of up to eight times your current depth, ForwardScan lets you relax and enjoy a safer day on the water.

Find Fish with CHIRP & StructureScan® HD Sidescan Imaging
Whether fishing is your life or just a casual hobby, any fishing trip will benefit from the extensive array of built-in sonar technology on the B&G VULCAN 9FS. Add a suitable transducer, available separately or bundled with your display, and the GO9 XSE works as a powerful fishfinder with CHIRP-enabled broadband sonar for clear detection of fish throughout the water column. With an optional HDI or TotalScan transducer, the VULCAN 9FS also offers StructureScan HD sidescan imaging for a picture-like view of fish-holding structure beneath and around your boat.

Simrad SonicHub®2 & Bluetooth® Audio Integration
If you’re not at home on the water without a good soundtrack, the Simrad SonicHub®2 marine audio system is the perfect companion to a B&G VULCAN 9FS display. Stream music from Bluetooth® connected tablets, smartphones, and other mobile devices, play MP3 files from a USB flash drive, or listen to the SonicHub 2’s built-in AM/FM radio. SonicHub 2 brings complete control of your audio entertainment to your VULCAN 9FS display, eliminating the need for a separate stereo head-unit and letting you listen to your music, your way.

GoFree™ Cloud Enabled with Built-in Wi-Fi
With Wi-Fi built in, the B&G VULCAN 9FS provides direct access to GoFree cloud services including easy wireless map downloads, software updates, and more. Whether connected to your home Wi-Fi with your boat trailered in the driveway, logged in to your marina’s Wi-Fi, or tethered to your smartphone out on the lake, you can access GoFree cloud services anywhere you have an internet connection. On the water, GoFree connects the B&G VULCAN 9FS to your mobile devices, mirroring your display’s screen on your smartphone or giving you full remote control from your tablet with the free GoFree Controller app.

Included:

Vulcan 9 Suncover
GO9 XSE & Vulcan 9 Edge Beze
GO9 XSE & Vulcan 9 Dash Mount Kit
4-Pin Power Cable
Bracket NSX 3009, NSS7evo3, Zeus3-7, GO9 and Vulcan 9
NSS knurled screws (pair L/R)

Technical Data

Display type	WVGA colour TFT LCD
Display size	9" widescreen
Display resolution:(pixels x pixels)	800 x 480
Backlight levels	LED / 1200 nits
Further functions	Waypoint Storage: 10,000 points total combined waypoints / route points
Languages	Standard Language Pack, Asian Language Pack, Eastern European Language Pack, Russia/Ukraine Language Pack, Middle Eastern Language Pack
Memory Card Capable	Chart card slot: Dual microSD
GPS-Antenna type	Built-in 10 Hz GPS
Operating temperature in use	15 °C to +55 °C (5 °F to 131 °F)
Waterproof	IPX7
Width	243 mm / 9.56 in
Depth	83 mm / 3.26 in
Height	171 mm / 6.71 in
Weight:	1.32 kg / 2.91 lb
Power consumption	12 W @ 13.8 V
Power supply (operating voltage)	12 V DC
NMEA2000 Pending Certification	1 port

Display size

9 Inch

Operating mode

Touch screen

Radar capable

Yes

Tablet control

Yes

Viewing angle

Downwards Sidewards Forwards

Delivery contents

Display
Mounting kit for panel installation
- Seal
- Mounting screws
Sunshade
Cables
Fuse holder and fuse
Protective covers
Documentation package
- Installation manual
- Quick guide
- Mounting template
Bracket mounting kit
- U-bolt
- Mounting screws
- Bracket mounts

Documents

Manual

PDF (11,21 MB)

Manual

PDF (4,84 MB)

Product safety

What other SVB customers have to say

100% real reviews

10 customer reviews

4.6 (out of 10 ratings)

5 Stars

(6)

4 Stars

(4)

3 Stars

(0)

2 Stars

(0)

1 Stars

(0)

100% recommend SVB

Advantages
Connection options (3)
Resolution (2)
Screen brightness (3)
Operation (1)
Price/performance ratio (4)
Mounting/Installation (4)

Disadvantages
Connection options (1)
Resolution (1)
Operation (2)

by Pere L.

4/29/2026 Verified purchase Variant: 81933

Satisfied with the purchase. I haven't installed it yet and can't comment on the details.

Satisfied with the product. I haven't installed it yet and can't comment on the details.

by Brendan M.

3/30/2023 Verified purchase Variant: 81494

Screen Mirror

The main reason for purchasing Vulcan was Screen Mirror. Plan is to keep Plotter at Vav Table, tablet at helm.
Difficulties downloading B&G software, Link software...
No help from B&G.
Dissapointed!!!.

Advantages
Resolution
Screen brightness
Price/performance ratio
Mounting/Installation

Disadvantages
Connection options
Operation

by KLaus-Dieter M.

10/24/2022 Verified purchase Variant: 81494

Super execution

navigation

Advantages
Connection options
Resolution
Screen brightness
Operation
Price/performance ratio
Mounting/Installation

by Nicola G.

6/28/2022 Verified purchase Variant: 81494

Arrived. Vulcan 9

The product arrived, together with the plotter there was an assembly manual, and a quick installation guide. The complete guide with all the operations that this plotter can do is missing. How do I get the complete guide to take advantage of all the functions of this article?

by Bram J.

5/12/2022 Verified purchase Variant: 81494

B&G - VULCAN 9 FS GPS, 9 inches

For me, the Simrad Go7 was just a bit too small on the 24-foot Tri, and the "Sailsteer", which is particularly useful for sailors, was also missing. So please 1x VULCAN 9 FS The first one was unfortunately defective and was returned The second is a great device, many functions Simple operation, just read through the most important things and try them out, then it works! The device is relatively light and does not have a deep, heavy housing, so it is ideal for rotary bracket mounting. Like the old Simrad, the B&G also has fast and good satellite reception, no additional antenna is necessary on the GRP boat. Like the Simrad, the Vulcan can do something on the back get hot, a gentle breeze to cool down can never hurt Next week on the water and try everything!

View all ratings

Rate product

How would you rate this product?

Disappointed

Completely fails to meet my expectations

Poor

Only some expectations are met

Meets my basic expectations

Good

Slightly better than my general expectations

Excellent

Fully exceeds my expectations

Click on the stars to rate

Customers ask customers

Technical question

Willem R. | Feb 10, 2024

Is the software updated of the vulcan 9 you are selling ?

Answer from SVB customer service

Andreas M. | Feb 27, 2024

Hi Willem, at the moment we don´t have the device on stock. From the manufacturer we normally recieve the devices with the latest software. In any case you can update the software easy by WIFI or with micro SD chart.

Technical question

Pekka K. | May 9, 2023

What asessories do I need for using AIS with this plotter?

Answer from SVB customer service

Andreas M. | May 9, 2023

Hi Pekka, you need an AIS device. AIS is available a receiver and as transceiver. All models we have in our standard delivery program you can see in the following link. https://www.svb24.com/en/category/ais-devices

Technical question

Stanislav K. | Jun 12, 2022

Hi, im thinking about the Vulcan 9 for my yacht. Now i have few qestions im thinkig about: - can i use the old depth sensor with coaxial wire from the old depthfinder? I need just the depth. (important) - I have an old Navico hydraulic autopilot (1996) - will it work together? (not so important) - the Navionics charts are some special or i can download it as i have it in my phone? Or is there some cheap source for charts as i would like to sail around the world again and dont want to spend all money for charts... (without charts is this device useless :-)) Thanks for any reaction! Stan

Answer from manufacturer

Denis S. | Jun 17, 2022

Hi Stan, you can only connect NMEA0183 or NMEA2000 devices to Vulcan9, no coax analog without interfacing to one of the above. Old AP won't work since it has no NMEA2000 interface and software. All kind of Charts will work from Navionics, C-Map and NV-Charts. But no chart from Navionics Mobile App. As example look online at the C-Map chart explorer to learn about coverage and sizes.

Translate this text

Technical question

Raimond N. | May 1, 2022

Can I directly connect NASA NMEA2000 Wind System (https://www.svb24.com/en/nasa-marine-nasa-nmea2000-wind-system.html) and also power it from chartplotter (only one device) ? Or do I need also NMEA2000 Starter Kit ?

Answer from SVB customer service

Andreas K. | May 2, 2022

Hi Raimond, you need the NMEA2000 Starter Kit for the power supply for the network.

Technical question

Maciej W. | Sep 27, 2020

Can it be connected as a secondary plotter to Zeus 3 deck plotter?

Answer from SVB customer service

Arne C. | Sep 28, 2020

Hi Maciej, No, this is not possible, because the Vulcan have no Ethernetport. You only can conntect them, by NMEA2000 to share sensordata like depth, GPS, SOG, Wind etc.

Answer

Maciej W. | Sep 28, 2020

Thanks a lot. But there will be no problem with 2 plotters consuming same data? Also can there be interference when trying to use one plotter GoFree functionality and tablet?

Answer from manufacturer

Denis S. | Oct 2, 2020

No problem at all. N2k data is available to all connected devices at same time. The FoFree connected tablet need to chose which plotter shall be shown. So either Zeus3 or Vulcan.

Translate this text
