MASTERVOLT ChargeMaster PLUS CZone Charger / 12 V / 50 A / 3 charging outputs
SVB item number: 65627
Manufacturer no.: 44310505
ChargeMaster PLUS CZone is the next generation of battery chargers that integrate multiple functions into one single device. Number of battery outputs: 3. Total charging current: 50 A. Product details
Having issues?
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
Are you already using this item?
Add to my boat now.
Available variants
MASTERVOLT
ChargeMaster PLUS CZone Charger / 24 V / 40 A / 3 charging outputs
€1,104.32
only €999.95
MASTERVOLT
ChargeMaster PLUS CZone Charger / 24 V / 20 A / 3 charging outputs
€534.31
only €483.95
MASTERVOLT
ChargeMaster PLUS CZone Charger / 12 V / 75 A / 3 charging outputs
€1,185.24
only €1,059.95
MASTERVOLT
ChargeMaster PLUS CZone Charger / 12 V / 100 A / 3 charging outputs
€1,533.91
only €1,379.95
MASTERVOLT
ChargeMaster PLUS CZone Charger / 24 V / 60 A/ 3 charging outputs
€1,360.17
only €1,229.95
MASTERVOLT
ChargeMaster PLUS CZone Charger / 12 V / 35 A / 3 charging outputs
€546.21
only €494.95
Product data
- SVB item number 65627
- EAN 816882022883
- Manufacturer no. 44310505
- Description MASTERVOLT - Charger ChargeMaster PLUS 12/50-3
- Device type Charger
- Network AC voltage 80 - 275 V
- Battery nominal voltage 12 V
- Max. charging current 50 A
- Charging outputs 3
- Battery Capacity 200 - 400 Ah
- Battery type Lead-Acid, AGM, Gel, Lithium (LifePO4)
- Power Lead No
- Integrated fan Yes
- Integrated charging cable No
- Temperature sensor can be connected Yes
- Optional remote display/operation Yes
- Width 210 mm
- Height 291 mm
- Depth 105 mm
- Weight 2.5 kg
- CAN Bus Yes
- Bluetooth No
- Continous Power 600 W
- Data protocol MasterBus, C-Zone
- AC connection Screw terminals
- DC connection Threaded bolt
- Protection from Short circuit, Overheating, Overloading, Overvoltage, Ignition protection
Accessories
Product details
The complete solution for fast and safe charging
ChargeMaster PLUS is the next generation of battery chargers that integrates multiple functions into one single device.
ChargeMaster Plus features the new "Battery's Best Friend" architecture, which allows it to charge a multitude of battery chemistries, sizes and voltages with the safe and fast 3-step+ charging method. For faster charging, Priority Charge redirects power to the weakest battery, Revival mode automatically brings even fully depleted batteries back to life, and the Pre-Float function (charge retention) eliminates the risk of overcharging smaller batteries.
The charging profile for MASTERVOLT MLI lithium-ion batteries is also included, and it is possible to create a customised, user-defined profile for lithium batteries from other manufacturers, for example, via an optional USB interface and the MasterAdjust software*.
*Download for free in the MASTERVOLT download section
Global charging
ChargeMaster Plus can handle all possible mains voltages and frequencies worldwide. The battery chargers can resist large voltage fluctuations and high temperatures, making them suitable for the harshest environments - perfect for use on boats and in cars. ChargeMaster PLUS units comply with CE, E-mark, ABYC, UL, SAE, CEC and RCM/C-Tick standards.
System simplicity
ChargeMaster PLUS chargers are self-explanatory! They display the charging phase of all three outputs in an easy to understand way. Robust and ergonomic connections save installation time.
Powerful connections
In modern applications, all components work hand in hand. The CAN-based MasterBus allows the charger to communicate with displays, shunts and power systems, including communication standards such as CZone, NMEA and CANopen. The ChargeMaster PLUS can operate as a power supply for sensitive communication equipment or during the construction phase of a boat.
Additional features
ChargeMaster PLUS ensures faster and safer charging!
ChargeMaster PLUS is the next generation of battery chargers that integrates multiple functions into one single device.
ChargeMaster Plus features the new "Battery's Best Friend" architecture, which allows it to charge a multitude of battery chemistries, sizes and voltages with the safe and fast 3-step+ charging method. For faster charging, Priority Charge redirects power to the weakest battery, Revival mode automatically brings even fully depleted batteries back to life, and the Pre-Float function (charge retention) eliminates the risk of overcharging smaller batteries.
The charging profile for MASTERVOLT MLI lithium-ion batteries is also included, and it is possible to create a customised, user-defined profile for lithium batteries from other manufacturers, for example, via an optional USB interface and the MasterAdjust software*.
*Download for free in the MASTERVOLT download section
Global charging
ChargeMaster Plus can handle all possible mains voltages and frequencies worldwide. The battery chargers can resist large voltage fluctuations and high temperatures, making them suitable for the harshest environments - perfect for use on boats and in cars. ChargeMaster PLUS units comply with CE, E-mark, ABYC, UL, SAE, CEC and RCM/C-Tick standards.
System simplicity
ChargeMaster PLUS chargers are self-explanatory! They display the charging phase of all three outputs in an easy to understand way. Robust and ergonomic connections save installation time.
Powerful connections
In modern applications, all components work hand in hand. The CAN-based MasterBus allows the charger to communicate with displays, shunts and power systems, including communication standards such as CZone, NMEA and CANopen. The ChargeMaster PLUS can operate as a power supply for sensitive communication equipment or during the construction phase of a boat.
Additional features
- MasterBus, CZone and NMEA 2000 communication interfaces
- Universal charger with three outputs
- Any type of lead-acid battery, including gel or AGM batteries, as well as large or small battery banks, can be gently charged on a single battery charger.
- Also suitable for charging MASTERVOLT MLI lithium-ion batteries
- Adjustable to the parameters for lithium batteries of other manufacturers via MasterBus USB interface (optional) and free Masteradjust software
- Charges multiple batteries simultaneously
- Safe charging: quickly detects charging status, ensuring a longer battery life
- Very wide operating range of 80-275 V AC, 35-70 Hz for worldwide use
- Compact, easy to install and connect
ChargeMaster PLUS ensures faster and safer charging!
Technical data
| ChargeMaster PLUS 12/50-3 | |
| Nominal output voltage (output 1,2 & 3) | 12 V |
| Number of battery outputs | 3 |
| Charging current in total | 50 A at 14.25 V |
| Recommended battery capacity (total) | 200 - 400 Ah |
| Nominal input voltage | 120/240 V, 50/60 Hz |
| Max. AC current (230 V / 120 V) | 3.5 A / 7.1 A |
| Power supply mode | Yes |
| Display | LED |
| Dimensions HxWxD | 291 x 210 x 105 mm |
| Weight: | 2.5 kg |
| Certifications | CE, CEC, DOE, ABYC, UL1236, cULus, SAE J1171, ISO 8846, ACMA |
| Charging characteristic | IUoUo, automatic / 3-stage for gel/AGM/lithium-ion |
| Temperature compensation (only for lead acid types) | -30 mV/°C, temperature sensor included |
| Voltage compensation | Yes, via MasterShunt |
| DC power consumption | < 2 mA (MasterBus off) |
| Current control function | via MasterBus or CZone |
| Power factor control | Yes, > 0.98 |
| Temperature range (ambient temp.) | -25 to +80 °C |
| Cooling | Vario fan |
| Waterproofing | IP 23 |
| Protection systems | Overtemperature, overload, short circuit, high/low battery voltage, spark protection |
| MasterBus compatibility | Yes |
Features
Discover the features that make this product stand out. From technical details to special functions – we’ve summarized all the key information for you.
Max. charging current
50 A
Charging outputs
3
Temperature sensor can be connected
Optional remote display/operation
CAN Bus
Product safety
Images for this rating
Customers ask customers
Technical question
Nigel S.
| Oct 25, 2023
Can the Chargemaster Plus Czone charge 2different types of batteries at the same time , for example Lithium house and AGM start battery. Is any other equipment needed
Answer from SVB customer service
Sven W.
| Oct 27, 2023
Hello Nigel, according to the manual, it is not possible to set and charge different battery types. Yours SVB-team.
Comparison
Availability / Price
Item no.
65627
65614
65628
65629
65612
65613
65615
65626
Customer ratings
Description
MASTERVOLT - Charger ChargeMaster PLUS 12/50-3
Mastervolt - ChargeMaster PLUS charger 24/40-3
MASTERVOLT - Charger ChargeMaster PLUS 24/20-3
MASTERVOLT - Charger ChargeMaster PLUS 24/30-3
Mastervolt - ChargeMaster PLUS charger 12/75-3
Mastervolt - ChargeMaster PLUS charger 12/100-3
Mastervolt - ChargeMaster PLUS charger 24/60-3
MASTERVOLT - Charger ChargeMaster PLUS 12/35-3
Width
210 mm
250 mm
210 mm
210 mm
250 mm
250 mm
250 mm
210 mm
Continous Power
600 W
960 W
480 W
720 W
900 W
1200 W
1440 W
420 W
Height
291 mm
384 mm
291 mm
291 mm
384 mm
384 mm
384 mm
291 mm
Max. charging current
50 A
40 A
20 A
30 A
75 A
100 A
60 A
35 A
Depth
105 mm
127 mm
105 mm
105 mm
127 mm
127 mm
127 mm
105 mm
Weight
2.5 kg
5.9 kg
2.5 kg
2.5 kg
5.9 kg
5.9 kg
5.9 kg
2.5 kg
Bluetooth
Battery nominal voltage
12 V
24 V
24 V
24 V
12 V
12 V
24 V
12 V
Network AC voltage
80 - 275 V
80 - 275 V
80 - 275 V
80 - 275 V
80 - 275 V
80 - 275 V
80 - 275 V
80 - 275 V
Battery type
Lead-Acid, AGM, Gel, Lithium (LifePO4)
Lead-Acid, AGM, Gel, Lithium (LifePO4)
Lead-Acid, AGM, Gel, Lithium (LifePO4)
Lead-Acid, AGM, Gel, Lithium (LifePO4)
Lead-Acid, AGM, Gel, Lithium (LifePO4)
Lead-Acid, AGM, Gel, Lithium (LifePO4)
Lead-Acid, AGM, Gel, Lithium (LifePO4)
Lead-Acid, AGM, Gel, Lithium (LifePO4)
Integrated fan
Integrated charging cable
Device type
Charger
Charger
Charger
Charger
Charger
Charger
Charger
Charger
Charging outputs
3
3
3
3
3
3
3
3
Optional remote display/operation
Temperature sensor can be connected
Power Lead
Battery Capacity
200 - 400 Ah
160 - 400 Ah
80 - 200 Ah
120 - 240 Ah
320 - 800 Ah
400 - 1000 Ah
200 - 500 Ah
140 - 350 Ah
AC connection
Screw terminals
Screw terminals
Screw terminals
Screw terminals
Screw terminals
Screw terminals
Screw terminals
Screw terminals
Connector pins
M6
Protection from
Short circuit, Overheating, Overloading, Overvoltage, Ignition protection
Overheating, Overloading, Overvoltage, Ignition protection
Short circuit, Overheating, Overloading, Overvoltage, Ignition protection
Short circuit, Overheating, Overloading, Overvoltage, Ignition protection
Overheating, Overloading, Overvoltage, Ignition protection
Overheating, Overloading, Overvoltage, Ignition protection
Overheating, Overloading, Overvoltage, Ignition protection
Short circuit, Overheating, Overloading, Overvoltage, Ignition protection
CAN Bus
Data protocol
MasterBus, C-Zone
NMEA2000, MasterBus, C-Zone
MasterBus, C-Zone
MasterBus, C-Zone
NMEA2000, MasterBus, C-Zone
NMEA2000, MasterBus, C-Zone
NMEA2000, MasterBus, C-Zone
MasterBus, C-Zone
DC connection
Threaded bolt
Threaded bolt
Threaded bolt
Threaded bolt
Cable terminal, Threaded bolt
Threaded bolt
Threaded bolt
Threaded bolt
