MASTERVOLT EasyView 5 Display
SVB item number: 65579
Manufacturer no.: 77010310
Controlling your Mastervolt system has never been easier. The EasyView 5 features a sharp, waterproof display which is clearly readable in daylight. Product details
Having issues?
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
Are you already using this item?
Add to my boat now.
Available variants
MASTERVOLT
Set: MasterShunt 500 + EasyView 5 / CZONE and NMEA2000 + T-fuse 500 A
only €799.95
To product
Product data
- SVB item number 65579
- EAN 816882020308
- Manufacturer no. 77010310
- Description MASTERVOLT EasyView 5 Display
Product details
Waterproof system monitor with ‘daylight readable’ display and intuitive touchscreen
Controlling your Mastervolt system has never been easier. The EasyView 5 features a sharp, waterproof display which is clearly readable in daylight. Thanks to the colour touchscreen and multi-language menu, the display is a pleasure to operate. Easily customizable favourite pages show all relevant system information at a glance.
Features:
The EasyView 5 completes any MasterBus system. With its handy functionality and compact size, the EasyView is ideal for yachts, vehicles and stationary systems. Applicable in various markets such as marine, mobile (recreational and professional), infrastructure, offshore, off grid and industrial. The possibilities are endless!
Some examples of the many possibilities:
Customize favourite pages to meet your specific needs for information and control, to show information in the most convenient way.
Use the EasyView 5 to adjust frequently used settings, like the shore fuse or to switch on your inverter.
In the system page you will find every possible system setting.
No surprises! The EasyView 5 helps to keep your system in top condition by assisting you with alerts. Logging of the alarms provides valuable insight in the operation of your system.
Technical data:
Controlling your Mastervolt system has never been easier. The EasyView 5 features a sharp, waterproof display which is clearly readable in daylight. Thanks to the colour touchscreen and multi-language menu, the display is a pleasure to operate. Easily customizable favourite pages show all relevant system information at a glance.
Features:
- Waterproof, ‘daylight readable’ colour display. Intuitive touch control.
- Customizable favourite pages.
- Log book for warnings and alarms.
- Buzzer and Home button.
- Easy mounting: front mount, wall mount or retrofit.
- MasterBus powered, or 12/24 V input.
- Easy updating through MasterBus and USB.
The EasyView 5 completes any MasterBus system. With its handy functionality and compact size, the EasyView is ideal for yachts, vehicles and stationary systems. Applicable in various markets such as marine, mobile (recreational and professional), infrastructure, offshore, off grid and industrial. The possibilities are endless!
Some examples of the many possibilities:
Customize favourite pages to meet your specific needs for information and control, to show information in the most convenient way.
Use the EasyView 5 to adjust frequently used settings, like the shore fuse or to switch on your inverter.
In the system page you will find every possible system setting.
No surprises! The EasyView 5 helps to keep your system in top condition by assisting you with alerts. Logging of the alarms provides valuable insight in the operation of your system.
Technical data:
| Power supply | MasterBus powered, or 12/24 V input |
| Resolution | 480 x 272 pixels |
| Colour depth | 16 bits |
| Display/read-out | 4.3 inch high contrast display with capacitive touch control |
| Languages on display | ENG, NL, DE, SP, IT, FRA, FIN, SWE, DEN, NOR |
| Mounting | Front mount, wall mount and MasterView Easy retrofit |
| Dimensions, hxwxd | 113 x 127 x 43 mm 4.4 x 5.0 x 1.7 inch |
| Weight | 0.315 kg 0.7 lb |
| Alarms | Integrated buzzer |
| Delivered with: | UV protection cover, wall mount casing |
| MasterBus-connection | Yes |
| Power consumption | < 160 mW (idle mode) |
| Connections | 2x MasterBus, USB, 12/24 V |
| Protection degree | IP67; waterproof front |
Documents
Product safety
Images for this rating
by
Philippe C.
11/21/2024
Verified purchase
11/21/2024
Verified purchase
Customers ask customers
Technical question
Chris B.
| Mar 10, 2022
good evening we currently have a mastervolt combi 12volt inverter charger system, +- a 2008 model, with a mastervolt chargemaster 12/35-3 unit. our chargemaster 12/35-3 system needs to be replaced. we thinking of getting the czone 12/50-3 chargemaster unit with the mastervolt smart remote remote control czone display. Can the czone units be compatable with the old school mastervolt combi inverter charger unit? Thank you for the advise needed regards
Answer
W P.
| Mar 11, 2022
Hi Chris, your old MASTERVOLT Combi is not compatible with new C-Zone units but probably it can communicate with the EasyView via a MasterBus Combi interface. Do you have the interface? It is not clear from your question what you actually want to do. Do you want to interact with both the old Combi and the new Chargemaster on a CZone/NMEA2000 display? You are referring to the combination of Smart Remote and new Chargemaster. Smart Remote can only communicate with a single device via MasterBus. You have set the question to the easyView. The easyView can communicate with several devices via the master bus. Please be more precise with your question and send it to [email protected]
