PHAESUN MARE FLEX 55 Solar Module / 55 W / Semi-flexible / 560 x 540 x 4 mm

To product

PHAESUN MARE FLEX 120 Solar Module / 120 W / Semi-flexible / 1190 x 540 x 4 mm

€349.27

only €269.95

Construction type: Semi-flexible

To product

At a glance!

None

Module connection: Front side

Connector cable: Round (multi-core)

Deck

Firm substrate

customers like: Weight

customers like: Price / performance ratio

Place of use: Inshore waters (2)

Place of use: Caribbean (1)

Place of use: North Sea (1)

by Jörn L.

Super Product flawless and the advice exemplary.

Nice small panel that fits in the chart table Bought this as a small panel to keep the batteries topped up when I'm not on board. Combined with a Votronic charge regulator, it works quite nicely. Stows inside my chart table, which is one of the safest places I can keep it to avoid accidental damage. Feels fairly robust though.

by Duncan H.

Excellent solar panel Solar panel attached to MPPT Victron Energy 7515 with yield above expectations. Very strong material with minimal weight. Recommended not only for maintaining beating.

by Andrea G.

Everything does what it should. The solar panel was placed on neoprene tape (strips) and screwed on.

by Petra V.

by Orth A.

Solar Top

Product data

SVB item number 27136
EAN 4250730202366
Manufacturer no. 310423
Description MARE FLEX 55 solar module
Construction type Semi-flexible
Nominal Power @ 12 V 55 W
max. Power Current (Imp) 3.24 A
max. Power Voltage (Ump) 17 V
Short circuit current (Isc) 3.49 A
Open circuit voltage (Uoc) 20.4 V
Connector None
Attachment Adhesive, Loops
Module connection Front side
Connector cable Round (multi-core)
Weight 2.6 kg
Length 560 mm
Width 540 mm
Height 4 mm
Wire cross section 1.5 mm²
Walkable No
Installation type Deck, Firm substrate
Daily yield in summer (Northern Europe) 165 - 220 Wh/Day
Daily yield in summer (Southern Europe) 220 - 275 Wh/Day
Use of light Monofacial

SVB recommends

SOLARFLEX®-X H1Z2Z2-K Solar Cable / black

from €1.70

3 Versions

Product details

The thin and light MARE FLEX 55 solar module delivers a maximum output of 55 Wp, is bendable and perfect for installing on sailing yachts and motor boats as well as on the roofs of caravans and trucks. It is also ideal for use in mobile applications, such as outdoor activities and camping. The front and back foil is made of ETFE and is weatherproof, yet extremely translucent. The module is particularly easy to install: It can either be fixed in place with construction adhesives (e.g. SIKA 291) or by using the integrated stainless steel eyelets. The solar module is supplied with a 5 m long connection cable with 2 x 1.5 mm² cable heads.

Construction type

Semi-flexible

Connector

None

Module connection

Front side

Connector cable

Round (multi-core)

Installation type

Deck Firm substrate

27136 - Solarmodul MARE FLEX 55 - 55 W - 20,4 V - 2.jpg

27136 - Solarmodul MARE FLEX 55 - 55 W - 20,4 V - 4.jpg

27136 - Solarmodul MARE FLEX 55 - 55 W - 20,4 V - 3.jpg

Documents

Datasheet

PDF (1,49 MB)

Manual

PDF (237,29 KB)

Item 27136

Systems

Product safety

What other SVB customers have to say

100% real reviews

12 customer reviews

4.7 (out of 12 ratings)

5 Stars

(11)

4 Stars

(0)

3 Stars

(0)

2 Stars

(0)

1 Stars

(1)

Advantages
Weight (2)
Price/performance ratio (1)
Quality (1)
Mounting/Installation (1)

Opinions
Place of use : Inshore waters (2)
Place of use : Caribbean (1)
Place of use : North Sea (1)

Customer images (1) from all reviews

by Thomas W.

6/2/2026 Verified purchase Variant: 27136

Solidly made, performance okay

I ordered the module for trickle charging, to be mounted in the sliding-door garage. It's nice and compact and well-made. Depending on the position of the sun, it produces between 10 and 40 watts. That's plenty for trickle charging throughout the week. During the day, it also covers a good portion of the typical daily power consumption (navigation, autopilot, refrigerator). A short motor trip in and out of the harbor fully charges the batteries. I'm very happy with this solution.

Advantages
Weight
Price/performance ratio
Quality
Mounting/Installation

Opinions
Place of use : North Sea

Images for this rating

by Vincent L.

4/13/2026 Verified purchase Variant: 27136

MARE FLEX 55

Excellent product; the construction seems very robust, the cells are sandwiched within the ETFE coating. I just installed it, glued with Sika 291UV, directly onto the deck in front of the companionway. I'm ordering another one right away to install in front of the mast.

Advantages
Weight

Opinions
Place of use : Caribbean

by Johannes S.

7/23/2025 Verified purchase Variant: 27136 in use on a Atlanta - Flamingo18

Top solar panel

Does what it's supposed to at a good price.

Opinions
Place of use : Inshore waters

by Orth A.

6/7/2025 Verified purchase Variant: 27136 in use on a Neptun Yachten - Neptun 22

Solar

Top

by Michael K.

6/6/2024 Verified purchase Variant: 27137

MARE FLEX 55 Solar Module / 55 W / Semi-flexible / 560 x 540 x 4 mm

Tip top!

After 6 months I am very satisfied. I removed the metal eyelets and screwed 2 directly onto the deck, slightly bent. Even if the manufacturer shirks his responsibility, they are made of the perfect material to walk on. The surface is also perfectly slip-resistant, although we try to avoid transverse loads as much as possible. I am now ordering 4 more for the deck.
I mounted 4x 150s on the bimini. However, they were too heavy for that and I had to reinforce them with light plastic tubes. It looks ugly, but is now very stable. We have just spent 4 days at anchor at 25-35kt, as well as around 6000nm at up to 45kt, and it holds. I also drilled out the eyelets and replaced them with the small Tenax. (They do corrode though!)

Images for this rating

View all ratings

Rate product

How would you rate this product?

Disappointed

Completely fails to meet my expectations

Poor

Only some expectations are met

Meets my basic expectations

Good

Slightly better than my general expectations

Excellent

Fully exceeds my expectations

Click on the stars to rate

Customers ask customers

Technical question

Urša G. | Oct 3, 2021

Dear Sirs, whats panels in real peak (W) and daily production (Wh) in a sunny day?

Answer

W P. | Oct 4, 2021

There are no further specifications from the manufacturer other than the technical module data, which were determined in accordance with the Standard Test Conditions (STC). This is understandable, as the module performance depends on various factors, such as the location, the resulting angle of incidence of light, brightness, the duration of sunshine as well as the ambient temperature.

Answer

Urša G. | Oct 4, 2021

Dear Sirs, I understand that data depends on various factors, so I asked customer (SVB enable customer to customer functionality) not SVB for experience in real about this summer's peak (W) and top daily production, kindly ask to provide this opinion. Thanks in advance.
