SIMARINE Radar tank sensor STR2 / NMEA2000 / Bluetooth
SVB item number: 35119
Manufacturer no.: STR2
The SIMARINE STR2 radar level sensor offers high-precision measurements for plastic tanks - reliable, modern and versatile. Thanks to radar technology, NMEA2000 interface and Bluetooth connection, it provides accurate data at all times and can be seamlessly integrated into an NMEA2000 system. Product details
Having issues?
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.
Are you already using this item?
Add to my boat now.
Available variants
SIMARINE
Radar Tank Sensor / 0 - 180 Ohm / 240 - 30 Ohm / 0 - 5 V output / Bluetooth
only €79.95
To product
Product data
- SVB item number 35119
- EAN 3830067941711
- Manufacturer no. STR2
- Description SIMARINE - Radar tank sensor STR2 NMEA2000
- Tank sensor type Micro radar
- For tanks containing Petrol, Diesel, Waste, Fresh water, Grey water
- NMEA2000 Yes
- Operating voltage 12 V (via NMEA2000)
- Material Plastic
- Ø 62 mm
- Height 32 mm
- Cable length 1 m
- Accessories for Chartplotters, Instruments, Tanks
Product details
The SIMARINE Radar Tank Transmitter STR2 provides high-precision level measurements for plastic tanks using the latest radar technology. Developed for use in modern ship systems, it delivers reliable values - regardless of the tank shape, fluid type or movements of the boat. This makes it ideal for fuel, fresh water, grey water and other on-board tank applications.
With a measuring range of 150 mm to 2000 mm, the STR2 ensures exceptional accuracy and stability, even in demanding conditions where conventional float sensors reach their limits. The non-contact radar measurement technology prevents mechanical wear and ensures a particularly long service life with minimal maintenance. Thanks to automatic calibration, the tank sensor is immediately ready for use.
For maximum compatibility, the STR2 outputs the measured values in NMEA2000 format, making the data available to any compatible display device in your network. Thanks to the integrated Bluetooth interface, users can easily configure the sensor and retrieve real-time level data via their smartphone.
The STR2 is a versatile, future-proof tank level sensor that can be seamlessly integrated into NMEA2000 networks.
With a measuring range of 150 mm to 2000 mm, the STR2 ensures exceptional accuracy and stability, even in demanding conditions where conventional float sensors reach their limits. The non-contact radar measurement technology prevents mechanical wear and ensures a particularly long service life with minimal maintenance. Thanks to automatic calibration, the tank sensor is immediately ready for use.
For maximum compatibility, the STR2 outputs the measured values in NMEA2000 format, making the data available to any compatible display device in your network. Thanks to the integrated Bluetooth interface, users can easily configure the sensor and retrieve real-time level data via their smartphone.
The STR2 is a versatile, future-proof tank level sensor that can be seamlessly integrated into NMEA2000 networks.
Documents
Manual
PDF (913,86 KB)
Product safety
Images for this rating
Customers ask customers
No questions asked yet. Be the first to ask a question!
More "Customers ask customers" available in the following languages
Comparison
Availability / Price
Item no.
35119
34752
Customer ratings
Description
SIMARINE - Radar tank sensor STR2 NMEA2000
SIMARINE - STR1 radar tank sensor
Height
32 mm
32 mm
Ø
62 mm
62 mm
NMEA2000
Operating voltage
12 V (via NMEA2000)
12 V
Material
Plastic
Plastic
Cable length
1 m
Tank sensor type
Micro radar
Micro radar
Sensor length shortenable
Resistance
0-190 Ohm, 240-33 Ohm
For tanks containing
Petrol, Diesel, Waste, Fresh water, Grey water
Petrol, Diesel, Waste, Fresh water, Grey water
Accessories for
Chartplotters, Instruments, Tanks
Instruments, Tanks
