YACHT DEVICES NMEA2000 USB Gateway

Practical and innovative USB gateway for transferring your NMEA2000 data directly to your PC. The gateway works in both directions, so that you can, for example, also send data from a PC to your chart plotter in the NMEA2000 network. In addition, the gateway supports a wide variety of navigation programs such as OpenCPN, Coastal Explorer, Polar View, OpenSkipper and many more. Connections: NMEA2000 (Micro-C), USB (Type A).


Operating modes:

In 0183 operating mode, data is converted from NMEA2000 to NMEA0183 and back. Support for NMEA0183 from practically all PC chart software. The conversion table can be found in the English manual.

In N2K operating mode, NMEA2000 data is sent directly to the PC in binary form. Many navigation programs are supported.

In RAW operating mode, all messages are sent in text form from NMEA2000 to the PC and back. You can monitor the data immediately with CAN-Log software or save the data.

In AUTO operating mode, the device analyses the connections with the PC program and automatically selects the best operating mode

Technical specifications

Power consumption via USB	35 mA
Power consumption via NMEA2000	13 mA
Cable length	450 mm
Housing length of the device	54 mm
Connections	NMEA2000 connector Micro-C / USB Type A
Included	NMEA2000 to USB gateway, English manual
