ACTISENSE NGX-1-ISO NMEA 2000 to NMEA 0183 Adapter

Name: NGX-1-ISO NMEA 2000 to NMEA 0183 Adapter
Brand: ACTISENSE
Price: 246.95 EUR
Availability: InStock
Rating: 5 (3 reviews)

SVB item number: 93982 Manufacturer no.: NGX-1-ISO

View Ratings (3)

View Ratings (3) Questions (2)

ACTISENSE NGX-1-ISO NMEA 2000 to NMEA 0183 Adapter Image 1 of 4

ACTISENSE NGX-1-ISO NMEA 2000 to NMEA 0183 Adapter Image 2 of 4

ACTISENSE NGX-1-ISO NMEA 2000 to NMEA 0183 Adapter Image 3 of 4

ACTISENSE NGX-1-ISO NMEA 2000 to NMEA 0183 Adapter Image 4 of 4

Used on a Sea & Yachting nvt

2 times in use on a Scanmar 33

Used on a First 211

Is in 3 shopping baskets right now, grab yours now!

Has been sold 2 times in the last 7 days

Recommended retail price: €278.02

only €246.95

-11%

VAT inc., ex-works

You save: €31.07

9 | in stock

Having issues?
If you are not redirected to PayPal, it could be due to your browser settings. Please check and if necessary deactivate the setting "Hide IP address" in the settings -> Safari -> Hide IP address. Please also check your browser for updates.

Are you already using this item?

Add to my boat now.

To wish list Compare

Available variants

ACTISENSE NGX-1-USB NMEA 2000 to USB Adapter

€297.00

only €262.95

VAT inc., ex-works

To product

At a glance!

12 V

NMEA2000

NMEA0183

customers like: Price / performance ratio

customers like: Quality

by Thomas F.

Top !!! Very competent advice based on my needs and the product recommendation derived from this. Connection and function as predicted

Read all product reviews

by Blue P.

Good gateway At least there is a gateway that works correctly

Read all product reviews

Product data

SVB item number 93982
EAN 5060998710553
Manufacturer no. NGX-1-ISO
Description NGX-1-ISO
Operating voltage 12 V
NMEA2000 Yes
NMEA0183 Yes
SeaTalk NG No
SeaTalk 1 No
USB No
WiFi No
AIS Support Yes
NMEA0183 Baud Rate 4800 - 230400 Baud
Cable length 1.8 m

SVB recommends

NMEA2000 Starter Kit / Micro-C

only €133.95

VAT inc., ex-works

NMEA2000 T-Piece / Micro-C

only €21.95

VAT inc., ex-works

-10%

DIGITAL YACHT USB-NMEA Serial Adapter Cable

only €58.95

VAT inc., ex-works

Product details

The new NGX-1 generation from Actisense combines the power of the two previous generation products (NGT-1 and NGW-1) into one and acts as a gateway to convert NMEA 0183 into NMEA 200 data and vice-versa.

The Actisense NGX-1-ISO allows you to share data bi-directionally from NMEA 0183 to NMEA 2000 (and vice versa). This allows you, for example, to connect older NMEA0183-capable devices to modern NMEA2000 systems. Similarly, data from NMEA2000 sensors can be converted into NMEA0183 data and thus displayed on NMEA0183-compatible devices.

ISO version with fully isolated NMEA0183 input and output. Supports Fast Heading at 10Hz. The baud rate of the NMEA0183 input and output can be changed from, for example, 4,800 to 38,400 (AIS) baud using the Actisense Toolkit software. Please note that this requires a PC with a serial interface (incl. SUB connector) or a corresponding USB to serial converter cable.
