TRAVEL 903 Electric Outboard / 2.5 HP / 915 Wh / short shaft

Explore the world on the water with the Torqeedo TRAVEL 903

The new Torqeedo TRAVEL 903 features an output of over 900 watts and is comparable to a 2.5 HP petrol outboard engine in terms of propulsive power. Thanks to the on-board computer with GPS-based calculation of the remaining range, it's like having a travel guide with you always.

The new Travel 903 now comes in a fresh and functional design.

Thanks to an impressive increase in power, this motor now offers a 14% increase in range compared to the Travel 1103 and features an extremely efficient propeller. And with an output of 900 W, it has more than enough to power boats weighing up to 1.3 tonnes,making it the perfect motor for small sailing boats or for exploring lakes and rivers with the family. Setting a new high bar in the light electric outboard sector, the motor promises a near-silent glide through the water and powerful thrust - all completely emission-free. This motor will revolutionise your boating experience and at unbeatable value for money!

1: On- board computer with GPS-based range calculation: Alarm at low charge level
2: Emergency Stop Magnetic Chip: Stops the engine in an emergency without affecting the water resistance
3: Short shaft
4: Quiet direct drive & immediate response
5: Lithium high performance battery integrated in the outboard engine: High energy density, excellent high current capability, safe
6: Charging socket and USB port: For charging with shore power, from 12V battery or solar. Via an (optional) USB adapter, the TRAVEL can also be used as a power source for smartphones, lights etc.
7: All connections and components are waterproof (IP 67)

Included in delivery: Torqeedo Travel 903 with battery, charger and magnetic chip kill switch
Note: For optimum protection in salt water, Torqeedo recommends the use of an anode.

The TRAVEL 903 - advantages

• Power: 900 W
• High-performance 915 Wh lithium-ion battery pack
• Upgraded transom mount
• Completely waterproof (IP 67)
• Immediate throttle response
• On-board computer with GPS-based range calculation
• Solar-chargeable – even during use
• Can be easily dismantled for transport and space-saving storage; outboard motor alone weighs only 11.3 kg (S) / 11.7 kg (L)
• A clean thing: no matter how and where you store your TRAVEL - no risk of anything leaking, no smell of petrol

Speed & running time
Tested on a fishing boat

	Speed in km/h (mph)*	Runtime in hours
Slow ride	approx. 3.9 (2.4)	approx. 13:00
Half throttle	approx. 6.1 (3.8)	approx. 2:57
Full throttle	approx. 7.9 (4.9)	approx. 1:10

Tested on an inflatable boat

	Speed in km/h (mph)*	Runtime in hours
Slow ride	approx. 3.0 (1.9)	approx. 13:00
Half throttle	approx. 5.8 (3.6)	approx. 2:21
Full throttle	approx. 7.1 (4.4)	approx. 1:12

* Depending on boat type, load, propeller and environmental conditions, information on speeds and ranges without guarantee

Information on range and speed

When travelling through water, displacement increases power required in proportion to the cube (third power) of the speed. This means that doubling water speed increases the power required eightfold. Conversely, it of course also means that only a slight reduction in speed will increase the range attainable significantly. Simply reducing speed by e.g. half a knot has a considerable effect on the remaining range. Since mental arithmetic to the power of three is quite tricky, the on-board computer of the Cruise constantly calculates the remaining range for you. To do this, it combines the consumption data from the motor with the charge level of the batteries together with the speed over water obtained via GPS. This means you can read the remaining range in real time from the Cruise's display. Using the TorqTrac App you can even read the remaining range from a map on your smartphone.

Technical Data

	Torqeedo Travel 1003
Input power in watts	900
Propulsive power in watts	440
Comparable petrol outboards (propulsive power)	2.5
Comparable petrol outboards (thrust)	3 HP
Maximum overall efficiency in%	49
Static thrust in lbs *	60
Integrated battery	915 Wh Li-Ion
Nominal voltage	29.6
Final charging voltage	33.6
Total weight in kg	17.3(S) / 17.7(L)
Weight of engine without battery in kg	11.3(S) / 11.7(L)
Weight of integrated battery in kg	6.0
Shaft length in cm	62.5(S) / 75(L)
Maximum propeller speed in rpm	1.450
Control	Tiller
Steering	+/-60° lockable
Tilting	Manual with grounding protection
Tilt angle	70°
Trim device	Manual, 4-step
Integrated on-board computer	Yes
Fully adjustable forward/reverse drive	Yes

* Torqeedo static thrust data is based on measurements according to worldwide valid ISO guidelines. The static thrust values of fishing motors are typically measured differently and are therefore higher. In order to compare Torqeedo static thrusts with conventional fishing motors, approximately 50% can be added to the Torqeedo static thrusts.
